HBI 200 Polarem 5W LED Wall Corridor Emergency (WCE)

Artikelnummer 2L0505WCE
  • Omschrijving

    Innovatieve armatuur met speciale lenstechniek waardoor het licht efficiënt te sturen is. Hierdoor is er weinig lichthinder. Ook heeft het instelmogelijkheden van lichtniveaus en sensoren. De elektronica heeft een lange levensduur van wel 100.000 branduren en LED L80/B10. De varianten met noodverlichting uit deze lijn zijn voorzien van een extreem duurzame accu met een levensduur van wel 10 jaar (bij draadloos beheer)! De lichtstroom is instelbaar op 100, 80, 60, 40 en 20% met een maximum van 425 lm. Bij autonomie van 1 uur is de nood lichtstroom 270lm en bij 3 uur 85lm.

    Type
    Serie 200 Polarem

  • Specificaties

    • Merk HBI
    • Artikelnummer 2L0505WCE
    • Soort Efficiënt & Innovatief
    • Mounting method Wall surface mounted
    • Function Escape route lighting/signage
    • Suitable for labelling type Other
    • Type of indicator Single/double-sided
    • Suitable for standby switching Ja
    • Suitable for continuous circuit Ja
    • Battery technology NiMH
    • Lamp type LED exchangeable
    • With light source Ja
    • Lamp holder Other
    • Number of lighting heads 1
    • Housing material Plastic
    • Housing colour Grey
    • Material cover Plastic, transparent
    • Voltage type AC/DC
    • Nominal voltage (V) 220 - 240
    • Type of control gear LED operating device current-controlled
    • Light distributor Focal lens
    • Constant light output (CLO) Ja
    • Degree of protection (IP) IP65
    • Impact strength IK10
    • Protection class according to IEC 61140 II
    • Rated ambient temperature according to IEC 62722-2-1 (°C) -20 - 40
    • Luminous flux in emergency mode (lm) 365
    • Max. system power (W) 7
    • Luminous flux in standby mode (lm) 365
    • Colour temperature (K) 4000 - 4000
    • Power factor 0,90
    • Recognition distance (m) 24
    • Nominal operation time (h) 1 - 3
    • Width (mm) 265
    • Height/depth (mm) 99
    • Length (mm) 148
    • Built-in width (mm) 265
    • Built-in height/depth (mm) 92
    • Built-in length (mm) 125
    • Type of wiring Ending
    • Number of poles 3
    • Conductor cross section (mm²) 2,50
    • Connection type Screw connection
    • Oplaadbaar Nee
    • Eenheid Stuk
    • Minimale bestelhoeveelheid 1
    • Orderveelvoud 1
    • Garantie (maanden) 60
Artikelnummer 2L0505WCE

HBI 200 Polarem 5W LED Wall Corridor Emergency (WCE)
